Top Oscillating Knife Cutting Machine for Sale in the United States
☆It is one of the large customized oscillating knife CNC digital cutter. All the machine configurations can be designed according to your needs. Now it is on hot sale.
Digital Cutting Machines Video
features
- Adopting Taiwan SYNTEC 6MB control system with 1.4 m control box, it can better support EOT-3 oscillating knife.
- Using a Germany EOT-3 oscillating knife, it is mainly used for soft materials.
- With the HQD air cooling spindle, it can fast and accurately process various soft materials.
Parameters
| Items | Parameter |
| Model | ELECNC-2030 |
| Working area | 2000*3000*200mm |
| Spindle | 3.5kw HQD Air cooling spindle |
| Spindle speed | 0-18000RPM |
| Motor and drive | 750W Leadshine servo motor with driver |
| Control system | Syntec 6MB control system with MPG handwheel |
| Inverter | 3.7kw Fuling inverter |
| Oscillating Knife | Germany EOT-3 oscillating knife |
| Working table | T slot and vacuum work table |
| Voltage | 220v, 3phase, 60hz |
Application
The CNC router machine with an oscillating cutter is good at cutting wood, acrylic, plastic and many other flexible non-metal materials. It is perfectly suitable for precise cutting of sealing material, cork, leather and foamed material. You can process sealing material, carbon fibre preggers, corrugated board, leather and cork, tissue and foil, expanded plastic slabs, carpets.
