Horizontal Panel Saw with Best Price in Switzerlan
☆This panel saw machine is mainly used in the woodworking industry or furniture manufacturing industry. It ia an vertical panel saw that can realize longitudinal sectioning, cross-section, or angled sawing of plywood, particleboard, fiberboard, veneer, laminated board, blackboard, spliced solid wood board, plastic board, etc.
Panel Saw Machines Video
Features
- It has the advantages of stable frame, fine manufacturing, beautiful and durable coating, etc.
- The machine key kits are all from world famous and international brands.
- It is precise, reliable, flexible, durable,and easy to maintain.
Parameters
| Dimensions | 3200*2540*900mm |
| Sliding table size | 3200*375mm |
| Sawtooth length | 3000mm |
| Sawtooth width | 1200mm |
| Sawtooth thickness | 78mm |
| Main saw diameter | 300mm |
| Scribing saw diameter | 120mm |
| Main saw speed | 4000/6000rpm |
| Scribing saw speed | 7000rpm |
| Spindle diameter | 30mm |
| Counter spindle diameter | 20mm |
| Main motor power | 5.5kw |
| Counter motor power | 0.75kw |
| Saw blade angle | 0-45° |
| Net weight | 700/800kg |
Application
The sliding table saw or panel saw is mainly used to cut wooden boards in the woodworking industry.It can cut various types of wood materials, like hardwood, softwood, MDF, particle boards, melamine boards, plywood, etc. Besides cutting, it can also make straight and inclined slots on the wooden boards by adjusting the angle of the saw blade.
