Purchase EPS Foam Engraving Machine for Price in Netherlands

☆It is a multi functional CNC foam engraving machine designed with a linear tool changer magazine. Therefore, various of tools can be changed automatically in the engraving process.

CNC Router Machines Video

features

  • The 4th spindle can rotate ±90° to realize 3d carving and complex design cutting.
  • With a linear automatic tool changer magazine, it greatly saves time and labor.
  • All the machine configurations can be customized according to your needs.

Parameters

Description Parameter
Model ELECNC-1530ATC-4 EPS
X,Y,Z Working Area 1500x3000x1100mm
Control system Taiwan SYNTEC control system
Working Voltage 380V, 3phase, 50Hz (Option)
Spindle 9kw Italy HSD air cooling spindle
Inverter 11kw Taiwan DELTA inverter
Motor and driver 850W YASKAWA servo motor and 1kw  YASKAWA driver, SHIMPO reducer
Gantry Structure Gantry moving
Table Surface T-slot working Table
Table structure EPS structure
X, Y, Z Transmission Helical rack on X, Y axis and Taiwan TBI ball screw on Z axis
X,Y, Z Rail Taiwan ABBA #30 linear guide
Lubrication system Automatic lubrication system
Tool Sensor Auto tool sensor calibration
Dust collection system 1.5kw new type double bag dust collection system
Wire High soft shield with copper wire to protect against static electricity

Application

Casting mold industry: It can be used for the precision production of various cast wood molds for various automobiles, ships, aviation, trains, etc. And also be used for research and development and production of automotive interior decoration and exhibition decoration materials.
Casting and sculpture industry: Processing and engraving of various casting process products, lost foam, exhibition decoration materials, and GRG decoration materials.
Building decoration industry: Processing and production of building decoration materials such as GRG and GRC.

Production Facility

Blue Elephant CNC Factory View
Blue Elephant CNC Router Machine Factory View

Quality Control & Testing

CNC Machine Quality Control Detail Image
CNC Machine Quality Control Images
