Automatic 3015 Quartz Stone CNC Machining Center at Good Price in Guatemala, Costa Rica
☆This stone CNC machining center is suitable for processing various kinds of stones such as granite, marble, quartz, etc. And it is widely used in the making of stone kitchen sinks, stone countertops, basins, etc.
CNC Machining Center Video
Parameters
| Model | ELECNC3015 |
| X,Y axis travel | 3000*1500mm, option: 1300*2500mm; 2100*3000mm; 2100*4000mm, etc |
| Z axis travel | 500mm, option: 400mm, etc |
| Spindle type | Kenturn 7.5kw water cooling ATC spindle |
| Inverter type | 7.5kw inverter |
| Tool magazine | 12pcs tool magazines |
| Tool holder with collet | 12pcs BT40 |
| Control system | Syntec 60WE |
| Driving system | 1KW YASKAWA servo driver and motor |
| Reducer | Japan Shimpo reducer |
| Machine structure | Heavy duty body with quenching treatment |
| Work table | Stone special working table |
| Linear guide | TaiwanLinear guide |
| Transmission | X,Y axis: Taiwan Helical Rack and Pinion Z axis:Taiwan TBI high precision ball screw |
| Lubrication system | automatic lubrication system |
| Tool calibration | Autotool sensor calibration |
| Cables | Germany Igus cables with CE, cUL certificate |
| Compatible software | Artcam / Aspire, etc |
| Command language | G Code & M Code |
| Traveling speed | 60m/min |
| Working speed | 0-30m/min |
| Re-positioning accuracy | ±0.03mm |
| System resolution | ±0.0025mm |
| Working accuracy | ±0.03mm |
| Working air pressure | More than 0.6mpa |
| Working voltage | 380V 3PH 50HZ/ 60HZ |
Application
A stone machining center is designed for the deep processing of quartz, marble, granite, slate, and other artificial stones. It can cut and drill holes, engrave letters and patterns, and mill and grind the stone surfaces. It is widely used to make kitchen countertops, bathroom washbasins, bar counters, coffee tables, stone statues and sculptures, tombstones and gravestones, and other artificial stone crafts and artworks.
Production Facility
Quality Control & Testing
